Impacts of Earthquakes and Soil Characteristics on Isolated Bridges

Seismic Isolation Technology

Many regions in the world and in Canada are prone to moderate to strong seismic activity that harms the safety and functionality of structures. Bridges are one of the most critical infrastructures in today’s society, serving as crucial arteries in transportation systems, especially in times of crisis, such as the period following a major earthquake. These infrastructures are particularly vulnerable to seismic action. Seismic isolation is an efficient technique which was developed in recent decades to mitigate seismic risk for important infrastructures. This technology allows reducing seismic forces and building more economic structures, thus contributing to the protection of the environment and the circular economy.

Seismic isolation technology is based on decreasing the fundamental frequency of structural vibrations to a value less than the predominant energy-containing frequencies of an earthquake in order to reduce the seismic force demand (Soneji & Jangid, 2008). Also, seismic isolation incorporates an additional damping mechanism to control the displacement demand. According to studies and based on evidence from past earthquakes, record characteristics and soil effects are two of the most important parameters impacting seismic performance of isolated structures (Jónsson et al., 2010; Roussis et al., 2003).

In fact, seismic ground motion is affected by the nature of a site and can be significantly amplified. More notably, ground motion from near-faults contains long velocity pulses with a very high peak displacement demand. Seismic isolation systems are vulnerable to such peak demands where their displacement capacity can be altered, which can seriously threaten their operation and, thereby, the very safety of the bridge.

This study aims to better understand the simultaneous effect of site conditions and fault distances on the performance of seismically isolated bridges and seeks to identify ways to mitigate the negative impact of near-fault earthquakes on seismic isolation systems.

Model of the Studied Isolated Bridge

In this study, 21 earthquake records were extracted from the PEER database website (PEER Strong Ground Motion Databases). Nine of them were within 10 km of the epicentre (Rrup <10 km) and seen as NF records (Bray & Rodriguez-Marek, 2004). NF records have higher characteristic values, especially in terms of Peak Ground Velocity (PGV), specific energy density, and damage index (Attalla et al., 1998; Malhotra, 1999). These records were registered on different soil conditions ranging from hard rock to very soft clay. Soil type is illustrated below as shear wave velocity, Vs. The higher the Vs, the stiffer the soil.

The selected case study bridge with conventional and isolated designs was chosen from Alper Ucak’s research work (Ucak & Tsopelas, 2008). The bridge has two equal spans braced on a circular ‎‎5.2 m-high concrete pier supporting a uniform solid slab. It is highly representative of commonly used bridge/highway overpasses in Canada and Quebec. The ‎isolation system is designed for a period T = 2.0 (s) and the displacement capacity of the ‎isolator is 5.5 cm. Assuming the bridge is in Montreal, Canada, the hysteresis parameters, isolation system behaviours, and 3D bridge model are shown in Fig.1.

Fig.1. Isolated bridge model and seismic isolation system hysteresis loops

Nonlinear time history analyses (NTHAs) were conducted on the model, with selected ground motions and maximum seismic demands determined from the obtained time history responses. Results are ‎discussed in the following section‎.

Significant Impact of Soil Type on SIS Efficiency

The isolation hysteresis loops, obtained from NTHAs, are shown in Fig.2. They illustrate that ‎ isolator displacement and energy dissipation‏ ‏allocate the highest amounts on soft ‎soils and NF records. Dissipated energies within the hysteresis loops as well as ‎forces transmitted to the structure are higher for the mentioned condition. The maximum acceleration and isolation displacement responses for Kobe (Japan) records are presented in Fig.3. It is obvious that the seismic isolation has considerably reduced the seismic acceleration ‎forces by a factor of up to 10 on stiff soils while this factor is only 2 on soft soils ‎for FF records. This shows that seismic isolation efficiency may be considerably altered in the presence of soft soils.‎

Fig.2. Isolation hysteresis loops

As shown in Fig. 3, the maximum deck displacements for isolated bridges are related to NF on soft soil records. In some cases, the isolator displacements are up to 4 times higher than the isolator displacement capacity, indicating that the level of isolation displacement demand is higher in NF zones, especially on soft soils. This trend is the same for base shear responses where the maximum responses are related to NF records on soft soils.

Fig.3. Left) Maximum acceleration responses; Right) Maximum deck displacements

Conclusions

Seismic responses of an isolated bridge subjected to NF and FF records on different ‎soils computed by NTHAs were compared and the following tendencies were obtained:

‎‎1- In the case of NF records, all mentioned seismic responses were amplified for isolated and conventional bridges. These ‎increasing tendencies were more severe on soft soils and this effect should be considered at the ‎design steps for bridges under such circumstances.‎

‎2- In the case of isolated bridges, NF records and soft soils lead to higher demands in terms of displacements. Ignoring this issue during the design phase leads to a significant underestimation and possible failure of the isolation system and the bridge ‎during a strong NF earthquake on soft soil sites.‎

‎3- On soft soils, the level of reduction in acceleration responses of the isolated bridge was limited. It shows that seismic isolation is more efficient for firm or rock soils than soft soils. Careful attention and ‎scrutiny are required in designing these technologies, depending on the structure’s distance from active faults and the type of soil.

Additional Information

For more information on this research, please read the following paper:

Cheshmehkaboodi, N.; Guizani,L. 2021. “On the Influence of Earthquakes and Soils Characteristics on Seismic Response and Performance of Isolated Bridges”. Arab J Geosci14,399 (2021). https://doi.org/10.1007/s12517-021-06451-6.
